Specifications
SCREEN Screen size 47 cm (19")
alphatronicsView wide-angle display (178°/178°) LED display
Image format 16:9 Widescreen
Resolution 1366 x 768
Contrast ratio 3000:1
Brightness value 250 cd/m2
Response time < 5 ms
Viewing angle 178 H, 178 V
SOUND Music output / Watt 2 x 5 W
Integrated speakers / radiating to the front / -
Stereo sound
Audio DSP-Technologie -
Passiv Bass -
alphatronicsAUDIO+
CONNECTIONS TV tuner
2x HDMI connections / AV in / AV out / Headphones (3,5 mm) / YPbPR connection (3,5 mm) / Digital Coaxial Out 10,8 - 26 V DC supply voltage
External power supply 100 - 240 V AC, 12 DC
alphatronicsSound Bluetooth module 4.2
Pairing via OSD menu
TUNER Triple-Tuner (DVB-S2, DVB-T2 HD, DVB-C Tuner HDTV MPEG2/4)
PAL B/G, NTSC, SECAM
Integrated display of the quality level (DVB-S2)
CI+-Slot (Common Interface)
Electronic Programme Guide (EPG)
Favourites list
Parental control
PhotoViewer 2x USB 2.0 connection / Media player
PLAYER DVD player integrated on the side
Formats: CD, DVD, VCD, MP3, DVD-R, DVD-RW, DivX, JPEG
FEATURES Automatic station search storage
Channel lists for European countries
Max. TV programme slots 999
Videotext TOP (100 pages)
Image modes 4
Sound modes 5
Sleep timer
Graphical OSD menu (multilingual)
GENERAL Weight (with/without base in kg) 3,25 / 2,95
Dimensions (with/without base, W x H x D in mm) 440 x 299 x 139 / 440 x 263 x 52
Housing color black / silver
VESA Standard (100x100)
On/off switch
Power consumption kWh/1000 18 W
Power consumption standby < 0,5 W
Energy efficiency class
SCOPE OF DELIVERY Remote control, AN5 DVB-T antenna, mains adapter, YPbPR adapter, AV adapter, 12 V cable, batteries, operating instructions
alphatronicsView wide-angle display (178°/178°) LED display
Image format 16:9 Widescreen
Resolution 1366 x 768
Contrast ratio 3000:1
Brightness value 250 cd/m2
Response time < 5 ms
Viewing angle 178 H, 178 V
SOUND Music output / Watt 2 x 5 W
Integrated speakers / radiating to the front / -
Stereo sound
Audio DSP-Technologie -
Passiv Bass -
alphatronicsAUDIO+
CONNECTIONS TV tuner
2x HDMI connections / AV in / AV out / Headphones (3,5 mm) / YPbPR connection (3,5 mm) / Digital Coaxial Out 10,8 - 26 V DC supply voltage
External power supply 100 - 240 V AC, 12 DC
alphatronicsSound Bluetooth module 4.2
Pairing via OSD menu
TUNER Triple-Tuner (DVB-S2, DVB-T2 HD, DVB-C Tuner HDTV MPEG2/4)
PAL B/G, NTSC, SECAM
Integrated display of the quality level (DVB-S2)
CI+-Slot (Common Interface)
Electronic Programme Guide (EPG)
Favourites list
Parental control
PhotoViewer 2x USB 2.0 connection / Media player
PLAYER DVD player integrated on the side
Formats: CD, DVD, VCD, MP3, DVD-R, DVD-RW, DivX, JPEG
FEATURES Automatic station search storage
Channel lists for European countries
Max. TV programme slots 999
Videotext TOP (100 pages)
Image modes 4
Sound modes 5
Sleep timer
Graphical OSD menu (multilingual)
GENERAL Weight (with/without base in kg) 3,25 / 2,95
Dimensions (with/without base, W x H x D in mm) 440 x 299 x 139 / 440 x 263 x 52
Housing color black / silver
VESA Standard (100x100)
On/off switch
Power consumption kWh/1000 18 W
Power consumption standby < 0,5 W
Energy efficiency class
SCOPE OF DELIVERY Remote control, AN5 DVB-T antenna, mains adapter, YPbPR adapter, AV adapter, 12 V cable, batteries, operating instructions
| Product data | |
|---|---|
|
Brand
|
Alphatronics |
